| Characteristics | Specification |
|---|
| CONTACT RATING | Dependent upon contact material. |
|---|
| MECHANICAL LIFE | 30,000 make-and-break cycles. |
|---|
| CONTACT RESISTANCE | 10mmax. initial @ 2-4VDC 100mAfor both silver and gold plated contacts. |
|---|
| INSULATION RESISTANCE | 1,000MΩmin. |
|---|
| DIELECTRIC STRENGTH | 1,000 V RMS@sea level. |
|---|
| OPERATING TEMPERATURE | -30°C to 85°C. |
|---|
