| Characteristics | Specification |
|---|
| CONTACT RATING | 0.4 VA max @ 20 VAC or DC max. |
|---|
| MECHANICAL LIFE | 40,000 make-and-break cycles. |
|---|
| CONTACT RESISTANCE | Below 100 mΩ¸ typ. initial @ 2-4 V DC, 100 mA. |
|---|
| INSULATION RESISTANCE | 500 MΩ¸ min. |
|---|
| DIELECTRIC STRENGTH | 500 Vrms min.@ sea level. |
|---|
| OPERATING TEMPERATURE | -30°C to 85°C. |
|---|
