TOGGLE SWITCH 鈕子開關

TG-MT04 series
TG-MT04 series
TG-MT04 series
TG-MT04 series
Toggle switch

TG-MT04 series

Vertical DIP toggle switch FEATURE Small contact resistance, accurate operating force error, diversified specifications and other advantages APPLICATIONS Suitable for consumer products, computer products, test instruments, communication equipment, etc


Manual

COMMON SPECIFICATIONS

CharacteristicsSpecification
Contact resistance  <20mΩ
Insulation resistance500VDC≥1000MΩ
Withstand voltage1500VAC
Electrical life1,0000 cycles
Mechanical life 4,0000 cycles
Operating temperature-25°C to 85°C.


DIMENSIONS

ModelDimensions




TG-MT04-F01

TG-MT04 series


TG-MT04 series

ModelDimensions




TG-MT04-F02

TG-MT04 series


TG-MT04 series

ModelDimensions




TG-MT04-F03

TG-MT04 series


TG-MT04 series
