TM-1085A series

Rocker switch FEATURE ‧ 17.50mm*17.50mm ‧ Slide on the 2D flat ‧ Integrated tact switch APPLICATIONS ‧ Digital cameras, automobiles, health care products, robots and industrial machinery, game consoles, drones.

Download Inquiry

Manual

COMMON SPECIFICATIONS

Characteristics	Specification
全阻值/Total resistance	5~100KA
额定功率/Rated power	0.0125W
工作电流/Working current	50MA DC12V
滑柄行程/Slide stroke	2mm
操作力距/Operating torque	120±50gf
寿命/life	1000000 Times
